Outdoor P4.8 Rental LED Screen Carbon Fiber for Corporate Events
500x500mm
CFO series is designed to offer a lightweight LED solution for
those circumstances where reducing weight can be a decisive factor.
Weighing just under 18 kg/m2, CFO is durable and lightweight which
compromises have been made to either the panel design or the visual
performance, so expect brilliant visual performance and high-grade
LED quality.
FEATURES
1. CARBON FIBER
Carbon fiber material makes the led panel durable and lightweight.
2. ONE-MAN INSTALLATION
The cabinet weight is only 4.5 kg, less than 18kg/sqm.
Smart lock system allows it to be installed by one man easily.
3. CURVEABLE
The panel can make concave and convex screens -12°~15°with cylinder
locks.
4. FRONT & BACK ACCESS
LED modules and power boxes can be removed from front or rear side.
One cabinet meets projects with different maintenance requirements.
5. ELABORATE DESIGN
Retractable covers at the corners offer considerate protection to
LED panel when assembling.
TECHNICAL SPECIFICATIONS
| Product Model: | CFO-4.8 |
| Pixel Pitch: | 4.8 mm |
| LED Type: | SMD1921 |
| Cabinet Dimension: | 500x500 mm |
| Module Size: | 250x125 mm |
| Cabinet Weight: | 5.5 kg |
| Cabinet Material: | Carbon Fiber |
| Driving Type: | 1/6 |
| Brightness: | 5000 nits |
| Max/Avg Power: | 800/200 W/m2 |
| Maintenance: | Front & Rear service |
| Environment: | Outdoor Use |
| IP Rating: | IP65 |
| Refresh Rate: | >3840 Hz |
| Installation Type: | Mounting/Hanging |
| Gray Scale: | 14 bit |
| Viewing Angle: | H:140°；V:140° |
| Operational Temp: | -20℃~+60℃ |
| Operational Humidity: | 10%~90% RH |
APPLICATION FIELD
Outdoor events
Outside ceremony
Movie premiere
Grassland Music Festival
Temporary venue
CASE
CONCLUSION
Our CF series carbon fiber led product are the number one choice
for your rental high grade led projects. With own-patented smart
lock system, technicians can install the screen quick and easy.
We keep doing research and development in led product. Making new
product and design by following the market trend and customer
needs.
If you want more information, please feel free to message us!
FAQ
Q1. Do you have spare parts for the order?
Yes, we do. Normally we will provide 3% of the spare for your
projects. If you need more spares, pls let us know in advance.
Q2. Is the module magnetic or screw fixing?
The module equips both magnets and screws. For outdoor using, the
magnetic modules will apply with 2 screws, so to fix the module
firmly to the cabinet.
Q3. How do you do front/rear service?
For front service, remove the 4 screws on the magnetic modules from
front, and then use vacuum tool to take out the modules, finally
take out the power box by unlocking the lock catch.
For rear service, remove the power boxes or the whole cabinet for
fixing the modules. (the cabinet can be removed easily in the
middle of the screen by smart lock system)
For more information about the service, please feel free to contact
us.
Q4. What is the warranty for this product?
The default warranty of our led display is 2 years. If you need a
longer warranty, feel free to let us know.
Q5. Is this product equipping power&signal 2 in 1 cable?
No, it isn’t. The cable is not integrated. Power and signal cables
are separate.
