P10.4 Glass Window Transparent LED Display 1000x500mm LED Cabinet
Shopping Mall
Indoor transparent LED display / Fixed or rental glass LED panel /
Shopping mall window LED video wall
FEATURES
With frame design, more stable, can do hanging and floor standing
installation.
Can be used for fixed or rental.
- ULTRA SLIM & LIGHT WEIGHT
9kg/sqm, one cabinet is only 4.5kg (0.5sqm). Save shipping cost.
The transparent rate is from 45% to 85%.
Modular design, the cabinet size can be customized according to on
site.
TECHNICAL SPECIFICATIONS
| Product Model: | P10.4 |
| Pixel Pitch: | 10.4-10.4mm |
| LED Type: | SMD2121;SMD1921 |
| Cabinet Dimension: | 1000×500x94 mm |
| Module Size: | 500x125mm |
| Cabinet Weight: | 4.5 kg |
| Cabinet Material: | Aluminum |
| Driving Type: | 1/2 |
| Brightness: | 800-5500 nits |
| Max/Avg Power: | 400/140 W/sqm |
| Maintenance: | Front or Rear service |
| Environment: | Indoor Use |
| IP Rating: | IP20 |
| Refresh Rate: | >3840 Hz |
| Installation Type: | Mounting/Hanging |
| Gray Scale: | 14 bit |
| Viewing Angle: | H:140°；V:140° |
| Operational Temp: | -40℃~+60℃ |
| Operational Humidity: | 10%~90% RH |
DRAWING
1000x500mm transparent LED display
APPLICATION
FAQ:
1. Q: Are you a manufacturer or trading company?
A: We are LED manufacturer, OEM & ODM optional, multi-solutions
provider, more than 10 years experience in LED industry! What’s
more, Visual World is a modern factory dedicated to applying
artificial intelligence to the LED industry.
2. Q: How about the warranty?
A: We provide at least 2 years warranty, and some products can be 5
years warranty. Even after the warranty, we can still repair
product for free, you just need to pay for the shipping cost.
3. Q: Can you customize my logo on LED display?
A: Of course, we can print your logo on PCB and LED Cabinet if you
need. Thus you will keep your own brand.
