    P0.7-P1.56 COB Small Pixel Pitch LED Display High-performance For Meeting Room

    Ask Lasest Price
    Brand Name : Visual World
    Model Number : P0.7
    Certification : EMC,CE,FCC,ROHS
    Price : Negotiate
    Payment Terms : T/T
    Supply Ability : 5000 sqm/month
    Delivery Time : 12 work days
    • Product Details
    • Company Profile

    P0.7-P1.56 COB Small Pixel Pitch LED Display High-performance For Meeting Room

    P0.7-P1.56 COB Small Pixel Pitch LED Display High-performance For Meeting Room


    Product Description:

    Full inverted COB process, protection technology with anti-knock, waterproof, moisture, put salt spray, (to put an end to the LED screen in the high humidity and high salt spray environment due to the lamp moisture caused by blind lights or caterpillars and other failures).

    Features:

    • The full flip-chip COB process includes protection technologies such as anti-collision, waterproofing, moisture resistance, and salt spray resistance, preventing LED screens from blinding or experiencing failures due to dampness in high-humidity and salt-spray conditions.
    • The module features 3D ink printing technology, enhancing contrast by 20% and lowering display brightness requirements. It supports an LCD status display panel for intuitive real-time monitoring of cabinet operations.
    • The module's PCB utilizes an HDI multi-layer circuit board design, ensuring good color uniformity and even temperature distribution.
    • The entire series incorporates Sunrise's energy-efficient common cathode chip, delivering higher performance with grayscale levels up to 16-bit.

    Technical Parameters:

    ModelP0.7P0.9P1.25P1.56
    Pixel Pitch0.7mm0.9mm1.25mm1.56mm
    LED TypeCOBCOBCOBCOB
    Cabinet Dimension600*337.5*35mm600*337.5*35mm600*337.5*35mm600*337.5*35mm
    Module Size150x168.75 mm150x168.75 mm150x168.75 mm150x168.75 mm
    Cabinet Weight4.6kg4.6kg4.6kg4.6kg
    Cabinet MaterialDie-casting AluminumDie-casting AluminumDie-casting AluminumDie-casting Aluminum
    Driving Type:1/361/361/271/48
    maintenanceFront serviceFront serviceFront serviceFront service
    Brightness0-2000 nits0-2000 nits1500 nits1000 nits
    Max/Avg Power390/136 W/m2420/147 W/m2330/100 W/m2330/100 W/m2
    IP Rating

    Front: IP65

    Rear: IP30

    Front: IP65

    Rear: IP30

    Front: IP65

    Rear: IP30

    Front: IP65

    Rear: IP30

    Refresh Rate>3840Hz>3840Hz>3840Hz>3840Hz
    Installation Type

    Mounting

    Hanging

    Stacking

    Mounting

    Hanging

    Stacking

    Mounting

    Hanging

    Stacking

    Mounting

    Hanging

    Stacking

    Gray Scale16bit16bit16bit16bit
    Viewing AngleH:170°;V:170°H:170°;V:170°H:170°;V:170°H:170;°V:170°
    Operational Temp-20℃~+50℃-20℃~+50℃-20℃~+50℃-20℃~+50℃
    Operational Humidity10%-90%RH10%-90%RH10%-90%RH10%-90%RH

    Applications:

    • Digital Signage system
    • Chain store
    • Street furniture
    • Billboard
    • Football stadium
    • Perimeter LED poster
    • Arena display, etc.




    Support and service:

    • Pre-Sale Service:

    We respond to inquiries within 24 hours. We offer market research and forecasts tailored to the customer's needs, and personalized, professional solutions. Datasheets and samples are available upon request. Additional services, such as custom packaging design and factory visits, can also be arranged.

    • In-Sale Service:

    We continuously monitor the production process and provide photos and videos based on customer requests. Spare parts are supplied at no additional cost.

    • After-Sale Service:

    We respond to complaints within 24 hours, and maintenance guidance or problem resolution is provided within 48 hours. The product comes with a 24-month warranty. Free technician training is available. A full set of documents, including installation instructions, software operation manuals, easy maintenance guides, and control system software CDs, is provided at no cost.


    FAQ:

    Q1: How to install?
    A1: Free of charge to provide detailed steel structure drawings and installation guidance and wiring diagram, free remote debugging. We can also send our engineers to the site to guide the installation.


    Q2: How long is the warranty period?

    A2: We offer a comprehensive two-year warranty covering structural integrity, installation, software programming, and product usage. Our dedicated after-sales team is available to assist with any queries or issues that may arise.


    Q3: Can it be customized?

    A3: We offer customization services to meet your specific needs. We can customize them to the way you want them to look, like size, shape, features, and more. In addition, we can customize your logo on the LED display.


    Q4: How to guarantee product quality?
    A4: We prioritize quality at every stage of production. Our rigorous quality control processes include stringent component selection, advanced manufacturing techniques, and comprehensive testing. Before shipment, each LED floor display undergoes a meticulous final inspection to ensure it meets our exacting standards.


    Q5: How fast can you provide after-sale technical support after encountering product problems?

    A5: We promise to provide professional after-sale technical support within 24 hours after receiving the customer's notice.
