P3 P6 P8 P10 Outdoor Flexible LED Display In Seamless Splicing IP
65 Protection
Product Description
Our Smart Module 320x320 is a cutting-edge display solution
designed to meet the rigorous demands of outdoor rental
applications. With its robust construction, advanced features, and
seamless integration capabilities, this module empowers you to
create stunning, high-impact visual experiences.
Product Features
High-Resolution Pixel Pitch Options
Advanced LED Technology
Versatile Cabinet Design
Durable and Lightweight Construction
Technical Parameters
Product Model | P3.81 | P6.67 | P8 | P10 |
Pixel Pitch | 3.81mm | 6.67mm | 8mm | 10mm |
LED Type | SMD 1921 | SMD3535 | SMD3535 | SMD3535 |
Cabinet Dimension | 640*640/960 mm | 640*640/960 mm | 640*640/960 mm | 640*640/960 mm |
Module Size | 320* 320 mm | 320* 320 mm | 320* 320 mm | 320* 320 mm |
Cabinet Weight | 25/17 KG | 25/17 KG | 25/17 KG | 25/17 KG |
Cabinet Material | Steel | Steel | Steel | Steel |
Driving Type | 1/10 | 1/7 | 1/4 | 1/2 |
Brightness | 5000 - 6000nits | 5000 - 6000nits | 5000 - 6000nits | 5000 - 6000nits |
Max/Avg Power | 700/210 W/㎡ | 700/210 W/㎡ | 700/210 W/㎡ | 700/210 W/㎡ |
Environment | Outdoor | Outdoor | Outdoor | Outdoor |
IP Rating | IP68 | IP68 | IP68 | IP68 |
Refesh Rate | >3840HZ | >3840HZ | >3840HZ | >3840HZ |
Installation Type | Mounting/Hanging | Mounting/Hanging | Mounting/Hanging | Mounting/Hanging |
Gray Sacle | 14Bit | 14Bit | 14Bit | 14Bit |
Viewing Angle | H:120° V:120° | H:120° V:120° | H:120° V:120° | H:120° V:120° |
Operation Temp | -20° ~ + 60° | -20° ~ + 60° | -20° ~ + 60° | -20° ~ + 60° |
Operation Humidity | 10% ~ 90 % RH | 10% ~ 90 % RH | 10% ~ 90 % RH | 10% ~ 90 % RH |
Advantage
Flexible
High Performance
Ideal Applications:
Q&A
FAQ:
Q1: What control system is used, and how does it work?
A1: We use the Nova Taurus Series asynchronous control system,
which supports cluster playback and management. You can easily
control it via various devices, including APP, smartphone, Wi-Fi,
iPad, laptop, PC, or through cloud control. It's very user-friendly
and convenient.
Q2: Can I place a sample order for an LED screen?
A2: Yes, we encourage sample orders for testing and quality
evaluation. Mixed samples are also accepted.
Q3: Can I have my logo printed on the product?
A3: Absolutely. Please let us know in advance and confirm the
design based on our sample before production begins.
Q4: What is your delivery time?
A4: Typically, delivery takes 7-15 days after the deposit is
received. However, the exact time depends on the order size and
items.
Q5: What is your warranty policy?
A5: We offer a 2-year warranty. We also provide full support for
structure design, installation issues, system troubleshooting, and
screen usage.
Our professional after-sales team, along with your dedicated sales
engineer, will assist with any questions you may have after your
order.
![]() |
